The new F9826M sets the trend for the medical version of mobile smart data terminals. It combines the high-end flagship power configuration with quality healthcare capabilities, making it an all-around excellent, rugged, anti-bacterial and anti-virus healthcare assistant. This device is designed to meet the demanding requirements of modern healthcare environments while providing reliable and efficient performance.
Model NO. :
F9826MCUP :
Qualcomm Oct-Core, 2.0GHzOperatng System :
Android 11Display :
6.0 in. Full High Definition(2160 × 1080), industrial-grade IPS displayMemory :
4GB RAM(6GB optional） 64GB ROM(128GB optional）Power :
Rechargeable Lithium-ion 5000 mAh minimum (3.85V), QC3.0 fast charging (up to 2.8 A )Weight :
259g (including battery)Drop Specifications :
Can withstand multiple falls from a height of 1.5m onto a concrete floorSealing :
IP67
| Physical Characteristics | |
| Dimensions | 163(H)×77.2(W)×13(T)mm6.4(H)×3.0(W)×0.51(T)inch |
| Weight | 259 g/9.14 oz.（ battery included） |
| Display | 6.0 in. Full High Definition(2160 × 1080), industrial-grade IPS display |
| Touch panel | Corning® Gorilla® Glass Dual-mode capacitive touch, supports stylus, ungloved finger or gloved finger input, multi-touch and wet hand operation |
| Backlight | 450 NITS, LED |
| Power | Rechargeable Lithium-ion 5000 mAh minimum (3.85V), QC3.0 fast charging (up to 2.8 A ) |
| Backup Power | backup super capacitor |
| Expansion Slot | Micro SD Card slot, up to 512GB |
| Expansion Ports | 10 Pin Rear connection: USB 2.0 signal ,UART signal, Trigger key signal, Charging port 5V/3A4 Pin Bottom connection: Charging port 5V/3A, support USB communication and OTG mode |
| SIM Slots | 2 x Nano SIM, 1 x e-SIM (Optinal) |
| Notification | Audible tone; Multi-color LEDs; Vibration |
| Voice and Audio | Speaker（2W),, Telephone receiver, Dual microphones |
| Keypad | On-screen keypad and enterprise keyboard |
| Buttons | Programmable; Scan on each side; volume up/down; power; push-to-talk (PTT) |
| Performance Characteristics | |
| CPU | Qualcomm Oct-Core, 2.0GHz |
| Operating System | Android 11 |
| Memory | 4GB RAM(6GB optional）64GB ROM(128GB optional） |
| User Environment | |
| Operating Temperature | -20℃ to +50℃ |
| Storage Temperature | -40℃ to +70℃ |
| Humidity | 5% to 95%，non-condensing |
| Sealing | IP67 |
| Drop Specification | Withstands multiple 1.5 meter drops to concrete |
| Tumble Specification | 1000 round 0.5 meter tumbles |
| Electrostatic Discharge |
+/-15 kV air discharge +/-8 kV direct discharge |
| Interactive Sensor Technology | |
| Standard Sensors | Proximity Sensor, Light Sensor, Accelerometer, Magnetometer, Gyroscope |
| Option | fingerprint sensor |
| Data Capture | |
| Scanning | ME5066/SE4710/N6703/N6803etc. professional 2D scanning engine |
| Camera | Front 5 MP fixed focus; f/2.4 apertureRear 16 MP auto focus; f/1.85 aperture; Flash LED generates balanced white light; supports Torch mod |
| NFC | High RF output power; ISO15693, ISO14443A/B, MIFARE: Mifare S50, Mifare S70, Mifare UltraLight, Mifare Pro, Mifare Desfire, FeliCa Supported cards |
| Wireless WAN | |
| WAN Radio Frequecy | TDD-LTE(B34/B38/B39/B40/B41) FDD-LTE(B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B17/B19/B20/B25/B26/B28A/B28B/B30/B66) WCDMA(B1/B2/B4/B5/B6/B8/B19)TD-SCDMA(B34/B39) CDMA2000 1x EV-DO Rev.A BC0 (800MHz) CDMA 1x GSM/EDGE/GPRS(850/900/1800/1900) |
| GPS | |
| positioning system | GPS L1 with A-GPS、Glonass、BeiDou、Galileo、QZSS、SBAS |
| Wireless PAN | |
| Bluetooth | BT5.1+ BR/EDR + BLE |
| Communication Distance | >10m |
| Wireless LAN | |
| Radio | IEEE 802.11 ac/a/b/g/n/ax ready/d/e/h/i/j/k/r/v/w（2.4G/5G Dual Band Wi-Fi） |
| Data Rates |
5 GHz: 802.11a/n/ac— up to 433 Mbps 2.4 GHz: 802.11b/g/n — up to 200 Mbps |
| Security and Encryption | WEP,WPA/WPA2-PSK,WAPI,WAPI-PSKEAP: EAP-TLS,EAP-TTLS,PEAP-MSCHAPv2, PEAP-TLS, PEAP-GTC, PWD, SIM, AKA |
| Fast Roam | Supports 802.11r Fast Roaming |
| Accessories | |
| Standard Accessories | Adapter Charger ×1、USB Type-C cable ×1、Rechargeable Battery ×1 |
| Optional | Glass Tempered Film、Protective Case、Hand Strap、Single-Slot( Charge+USB/Etherne)、 Snap on Trigger Handle、RFID Handle、OTG Cable |
The new generation of the medical version of F9825M sets a new standard in performance and user experience. It not only boasts an uncommonly battle-hardened body configuration but also features excellent medical quality and a chemical-resistant shell design, making it ideal for demanding medical environments. Additionally, it supports multiple barcode readings, including Pharmacode and UDI code, ensuring versatility and efficiency in various medical applications.
